Collingsworth County, Texas
Water well drilling in Collingsworth County
TurnKey Wells helps Collingsworth County property owners move from county records to a clear drilling estimate. Tell us where the property is and what the well needs to support.
- Address-based project intake
- Property-specific planning
- Clear next steps
Have land in Collingsworth County? Start with the property address and your water needs.
What nearby household well records tell you
Collingsworth County has 193 domestic records, including 188 with a positive total depth. Their median reported depth is 130 feet, the middle half runs from 99 to 160 feet, and the upper planning marker is 200 feet. The full recorded domestic range is 30 to 425 feet.
Five domestic rows do not carry a positive total-depth value and are not part of the depth calculation. Fifty-nine domestic records include a positive pump depth; that smaller historical subset has a 105-foot median and should not be treated as a prescribed setting. Property planning still depends on location, intended use, access, pump and power needs, testing, and service access.
Recorded domestic well depths
The middle half of reported domestic depths
Collingsworth County records serve different purposes
The county file is not one group of identical water wells. Separating household wells from stock, irrigation, test, and monitoring records makes the local depth picture more useful.
Domestic depth logs
Positive household total-depth logs. The median is 130 feet, the middle half runs from 99 to 160 feet, the upper marker is 200 feet, and the recorded range is 30 to 425 feet.
Stock-well depth logs
Positive-depth records tied to livestock use average 139.6 feet, with filed depths from 40 to 380 feet. They add ranch context but should not replace nearby household records.
Irrigation wells
Irrigation records average 174.4 feet, with a 14-to-415-foot recorded range. Their demand and equipment plans differ from household completions.
Test wells
Test-well records average 192.3 feet, with filed depths from 40 to 414 feet. Their reporting purpose differs from a household completion, so they belong in a separate comparison group.
Monitor wells
Monitor records average 38.2 feet, with filed depths from 27 to 105 feet. Blending them with producing-use wells would create a number that belongs to no specific project.
Collingsworth County’s well records need to be compared by purpose
Stock and irrigation records outnumber household records, while monitor rows are much shallower. Keeping those uses separate prevents a blended average from becoming a misleading household assumption.
Source and method: Texas Water Development Board Submitted Driller Reports. Collingsworth County records are grouped by reported use, and this page summarizes positive depth values within those groups. Data verified August 22, 2026.
The complete job is more than drilling by the foot
Collingsworth County records help frame the depth conversation, but the complete system depends on the property, intended water use, and equipment needed to deliver it.
Property access
Rural roads, gates, overhead lines, utility conflicts, weather access, turning room, and space for the drilling rig.
Water demand
Home use, livestock, irrigation, storage, and peak daily needs.
Pump and power
Pump selection, electrical service, controls, pressure tank, line runs, and trenching.
Complete installation
Casing, testing, treatment, storage, plumbing, freeze protection, cleanup, and startup.
Get a drilling estimate built around what your Collingsworth County property actually needs.
Share the address, intended use, and timing. We will follow up to understand the project and explain the next step.
Know what should be included before work begins
A drilling quote is easier to compare when each major piece is visible. Pump selection, electrical support, pressure equipment, storage, treatment, freeze protection, service access, and line runs can matter as much as drilling footage. The Texas water well drilling cost guide explains the major cost categories.
- Mobilization and setup
- Drilling and casing
- Pump and controls
- Pressure tank
- Power and trenching
- Storage and treatment
- Water testing
- Site cleanup
Pre-Drill Intelligence Report
The county information on this page shows broad patterns. The paid report narrows the research to one Collingsworth County property before you compare drilling quotes or choose the next step for your land.
- Nearby recorded wells and reported depths
- Property access and site-planning questions
- Questions to ask before drilling begins
- A clearer picture of the complete water system
Understand the ground before you drill. The groundwater database contains 1,483 Collingsworth County rows: 661 are labeled Other, 437 Blaine, 267 Seymour, and 99 Blaine/Other, with only small Ogallala and mixed-label groups. The Seymour Aquifer guide and Ogallala Aquifer guide provide regional context, but historical labels do not identify the producing interval, depth, yield, or water quality for a property. Scout checks returned Mesquite Groundwater Conservation District for Wellington and an interior point, but no district near one boundary; check the exact tract with the Texas groundwater conservation district lookup. The county’s 160 plugged-well rows show county history, not proof about a specific property. Use the Texas water-well disclosure guide when an existing well is part of a sale.
From property address to drilling conversation
Tell us about the property
Share the address, how the water will be used, and when you hope to begin.
We review the project
We look at the location and follow up for any details needed to discuss the estimate.
Plan the drilling work
You receive a clear next step for the drilling quote and complete water system.
Plain answers before you plan the work
What do Collingsworth County household well records show?
The county file includes 188 usable domestic total-depth logs with a 130-foot median and a middle band from 99 to 160 feet. A property-level comparison is still needed before planning a new well.
Why can a Collingsworth County average be misleading?
Stock and irrigation records outnumber domestic records, while monitor wells are much shallower. Separating records by reported use produces a more useful household planning picture.
What do the county’s aquifer labels tell you?
Blaine and Seymour appear often in the historical groundwater file, alongside Other and mixed labels. Those records provide context but do not identify depth, yield, water quality, or the aquifer serving a specific tract.
Can a historical pump depth set a new pump?
No. The 59 positive domestic pump-depth values are a smaller historical subset. A contractor should evaluate water level, drawdown, demand, pump characteristics, and the completed well.
What information helps prepare a drilling estimate?
Share the property location, site access, intended water use, expected demand, available power, and any existing well information so the estimate can reflect the work the site may require.
Water Well Drilling Across Collingsworth County
From acreage around Wellington and Quail to rural properties near Samnorwood and Dodson, Collingsworth County planning starts with the location, intended use, access, power, and nearby domestic records. Mailing-city labels are orientation aids, not proof that records share geology or jurisdiction. Share the property location and water needs to discuss the next step.
